Binotech
Road Marking Materials
Product Features and Advantages
KTRM AWR™ All Weather Road Marking material manufactured in Malaysia using hydrocarbon binder incorporating all weather beads that reflects in wet and dry conditions.
- Provides wet and dry reflectivity during day and night
- High skid resistance for safety purposes
- Complies with JKR and MHA new specification for road marking
- Ease of application using conventional method
- Proven product in providing proper delineation to road users
- ISO Certified Standards
Application
Using traditional manual or motorised screed machine with double drop dispenser.
Product Features and Advantages
KTRM Thermoplastic Road Marking incorporates durable and hight performance reflective glass beads in the intermix and surface drop to ensure maximum performance on all types of road surfaces.
- Easy Installation
- Fast Drying
- Strong Adhesion
- Durable
- High Reflectivity
- Abrasion Resistance
- Crack Resistance
- Suitable for all types of road surfaces
Road Sign Materials
Product Features and Advantages
- Excellent torsion strength
- Outstanding fireproofing characteristics
- Excellent impact resistance
- Excellent weather resistance
- Even coating and various colours
- Easy to process and install
- Easy to maintain
Technical Specification
Size Available:1220 x 2440 x 3mm
1220 x 2440 x 4mm
1220 x 3660 x 3mm
1220 x 3660 x 4mm
Customized Sizes Available
Applications:Road Signage, Curtain Wall, Repaired Building, Dado, Separation Wall, Advertising Plate
High Intensity Prismatic Grade Type4 Grade
HIP 4000 (Mosaic Pattern)
Reflomax High Intensity Prismatic Series 4000 with a high level of retroreflectivity suitable for providing information to the drivers in various traffic situations with long-term reflectivity and durability especially at night.
Series HIP4000, as manufactured by Reflomax meets the stringent retroreflective requirements given in the ASTM D4956-16 standard for Type VI retroreflective.
Code Number: HIP4100 (Stripe Pattern) / HIP 4000 (Mosaic Pattern)
Main Applications: Traffic signage & Permanent signs
Reflective Technology: Prismatic
Durability: 10 years when properly converted and installed
Release Liner: Polypropylene film, silicone coated on one side
Adhesive: Permanent pressure-sensitive adhesive (Don’t use heat gun)
Application Surface: Chemically treated or conversion coated aluminum
Application Temperature: Minimum 15℃ (60˚F)
In Use Temperature Range: -10˚ to 65℃ (14˚ to 15˚F)
Width: 24″, 48″
Length: 50yds/roll
Compliance: ASTM D 4956 specifications for Type IV
Colors: White, F.Yellow Green, Yellow, F.Orange, Orange, Red, Green, Blue, Brown
Conversion Method: Screen Printing, UV Inkjet Printing, Thermal Die-Cut, Flat Bed Sign-Cut, Drum Roller Sign-Cut, Steel Rule Sign-Cut, Latex Digital Printing
Solar Powered Road Signs
- ⦿
- Solar Powered Arrow
- Solar Powered Bridge Panel
- Solar Powered Double Arrow
- Solar Powered Keep Left Sign
- Solar Powered Chevron
- Solar Powered Road Divider Marker
- Solar Powered Sarjan Chevron
- Solar Powered Warning Light
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: 1150mm X 1000mm
Solar Panel: 18V 4 watt
Battery: 6V 4AH
LED: 78 pcs ∅10mm Amber Colour
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: 300mm X 900mm
Colour: White Background with Slopping Red Stripes
Solar Panel: 18V 2 watt
Battery: 6V 4AH
LED: 24 pcs ∅10mm Red
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: 750mm x 750mm
Colour
– Background: Yellow
– Arrow: Black
– Border: Aluminium Frame 50mm Thickness
Solar Panel: 18V 2 watt
Battery: 6V 4AH
LED: 44 pcs ∅10mm Red Super Bright Led
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Applications: Pavement Shoulder Indicator, Center Divider Edge Indicator
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: ∅750mm
Colour
– Background: Blue
– Arrow: White
Solar Panel: 18V 2 watt
Battery: 6V 4AH
LED: 27 pcs ∅10mm Yellow Super Bright Led
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size:750mm x 600mm
Colour
– Background:Yellow
– Arrow:Black
– Border:Aluminium Frame 50mm Thickness
Solar Panel:18V 2 watt
Battery:6V 4AH
LED:90 pcs ∅10mm Red
Flashing Rate:60 flashes/min. ±10%
Operation Time:At Night
Applications:Curve Road, Hazard Warning
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: 750mm X 750mm
Color
– Background: Yellow
– Arrow: Black
– Border: Aluminium Frame 50mm Thickness
Solar Panel: 18V 2 watt
Battery: 6V 4AH
LED: 44 pcs ∅10mm Red Super Bright Led
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Applications: Pavement Shoulder Indicator, Center Divider Edge Indicator
Product Features and Advantages
- Built-in solar panel with fully automatic rechargeable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Size: 2620mm x 600mm
Colour
– Background: Yellow
– Arrow: Black
– Symbol: Black
Solar Panel: 18V 4 watt
Battery: 6V 7AH
LED: 162 pcs ∅10mm Red
Flashing Rate: 60 flashes/min. ±10%
Operation Time: At Night
Applications: Curve Road, Hazard Warning
Product Features and Advantages
- Built-in solar panel with fully automatic rechargable system
- Super bright led for continuous operations and longer life span
- Fully functional in heightened visibility and all weather conditions
- Easy installation with no cable required
- Durable, reliable and maintenance free
Technical Specification
Solar Panel
Type: Monocrystalline Sillicon Tempered Glass
Voltage: 17.5V
Current: 0.57A
Output: 10W
Dimension: 356 x 310 x 28mm
Battery
Type: Sealed Lead Acid
Voltage: 12V
Current: 7AH
LED
Colour: Amber
Qty of LED: 204 pcs
Flashing Rate: ±60 pulse per minute
Operation Time: 24 hours
Flashing Function: Synchronised or Flashing
Body Material: E.G. Powder Coated
Weight: 12 kg±
Body Fixture: 12 inch
Application: Traffic Warning Light, Pedestrian Crossing, Curve Road, T-Junction
Road Furniture Accessories
- ⦿
- Hazard Warning Barricade Tape
- Crystallite Glass Road Stud
- Delineator Post
- Kilometer Post
- Plastic Road Barrier
- Road Stud
- Reboundable Post
- Robotic Flag Man
- Baton Light
- Concrete Road Barrier
- Convex Mirror
- Delineator String
- Guardrail
- Rubber Speed Hump
- Safety Vest
- Blinker Light
- Safety Cone
- Square Reflective Flag
Product Features and Advantages
- Color: Red & White
- Size: 3″(W) x 200 metres
Product Features and Advantages
- Exposed area is 100% retro reflective
- High compression strength and durability
- Most effective solution to improve visibility for unlighted roads and highway
- Slip proof surface
- Easy installation
- Maintenance free
Technical Specification
Material: Tempered Glass
Attachment: Embedding with Adhesive/Epoxy
Dimension: Diameter 100 ±3mm x 50 ±3mm
Height of protruding part: 19mm
Weight: 540 ±20g
Compressive Strength: >60 metric tons (Break Load)
Reflection Type: 360 Retro Reflective
Colour: White or Yellow
Product Features and Advantages
- Reflective sheetings for continuous operation and longer life span
- Fully functional and heightened visibility in all weather condition
- Easy installation with no cable required
- Durable, reliable and maintenance free
Type A : With JKR Logo
- Consist: Primary & Secondary Destination and Distance
Type B : Without JKR Logo
- Consist: Primary Destination and Distance only
Product Features and Advantages
- Slop in concept ensure fast and easy assemble and dismantle of product
- Lightweight and does not rust or corrode
- Standard Colour: Red or White
- Finest Polyethylene material
- Long life span
Product Features and Advantages
- Designed to provide road users with brighter raised pavement marker for application on sharp curves, gore areas, lane delineation and other applications.
- Durable aluminium body with high impact strength and tough retroreflective lens
- One way – the colors are one way Yellow or Red
- Two ways – Two ways Yellow or Two ways Red
Product Features and Advantages
- Most Durable Post available
- High Impact & Wheel-over resistance
- Returns to vertical every time
- Unbreakable
- No Fade or Discolour
- Tested over 300,000 impacts & wheel-overs
- Warranty for 3 years
- Fast and Easy Installation
- Not affected by UV
- Recyclable Material
- Temperature Resistant -30°C to +80°C
- Low Maintenance
- Availabe in 750mm, 450mm & 300mm height
- Highest quality microprismatic reflective sheeting
Applications
- Merging Lanes
- Roundabouts
- Carparks
- Toll Booth Approaches
- Intersections
- Work Zones
- Traffic Calming Centres
- Centerline Medians
- Exit Roads
Product Features and Advantages
- Single hand
- Height : 6ft (Adjustable)
- 12v Battery, NH 60
- C/w safety helmet, rain suit and flag
- 6 months warranty for hand and motor
Product Features and Advantages
- Handheld baton light
- Comes with batteries
- Two signalling functions: Static flashing, Non-flashing
- Colour: Fluorescent red orange
Product Features and Advantages
- Mirror Sizes – 600mm, 800mm and 1000mm diameter
Product Features and Advantages
- 3” x 3” String Delineator Reflective
- Flexible & Durable
- Length: 50 pcs x 50 meters (Double Sided)
- Colour: Fluorescent Red Orange / Fluorescent Lime Yellow
Product Features and Advantages
- Rectangular modular unit
- Size: 360mm (L) x 260mm (W) x 50mm (H)
Product Features and Advantages
- 4 pcs High Brightness LEDs, high visibility (> 500m)
- Working Mode: Flashing-Bright
- Flash Frequency: 60/min
- Voltage: 6V (4R 25)
- With photo-resistance, automatically flashing night & close daytime;
- Colour: Amber
- With metal bracket for fixing.
Product Features and Advantages
- Soft PE with rubber base
- Band: 6″ White reflective band around cone
- Height: 750mm, 1000mm
- Color: Fluorescent Red Orange
Product Features and Advantages
- Size of Flag: 220mm (W) x 240mm (L)
- Size of Handle: 475mm (L) x 23mm (Dia.)
- Flag area: 225mm sq.
- Colour: Fluorescent Red Orange
